A scourer wire drawing machine is a specialized piece of equipment used in manufacturing to produce scourer wires, which are used in the production of cleaning scourers or scrubbers. These machines are designed to draw and shape wires from raw materials, such as stainless steel or galvanized wire, into the desired diameter and form needed for making scourers.
Key features and functions of a scourer wire drawing machine include:
Wire Drawing: The primary function of the machine is to draw or reduce the diameter of raw wire through a series of dies, gradually shaping it to the desired thickness.
Die System: The machine is equipped with multiple sets of dies, each with decreasing hole sizes, through which the wire is pulled to achieve the desired thickness.
Tension Control: Proper tension control ensures that the wire is drawn uniformly and smoothly through the dies, resulting in consistent wire thickness.
Scrubber wire drawing machine | |||
Power | 8KW | ||
Voltage | 380V | ||
Size | around 1800*1100*2700mm | ||
Usage | drawing 410/430 stainless steel wire from 0.7mm to 0.13mm | ||
Output | 10KG/Hour | ||
Weight | around 1Ton | ||
Works Efficiency | A person can operate 7-8 machines at the same time | ||
Packaging | Wooden case |
A scourer wire drawing machine is a specialized piece of equipment used in manufacturing to produce scourer wires, which are used in the production of cleaning scourers or scrubbers. These machines are designed to draw and shape wires from raw materials, such as stainless steel or galvanized wire, into the desired diameter and form needed for making scourers.
Key features and functions of a scourer wire drawing machine include:
Wire Drawing: The primary function of the machine is to draw or reduce the diameter of raw wire through a series of dies, gradually shaping it to the desired thickness.
Die System: The machine is equipped with multiple sets of dies, each with decreasing hole sizes, through which the wire is pulled to achieve the desired thickness.
Tension Control: Proper tension control ensures that the wire is drawn uniformly and smoothly through the dies, resulting in consistent wire thickness.
Scrubber wire drawing machine | |||
Power | 8KW | ||
Voltage | 380V | ||
Size | around 1800*1100*2700mm | ||
Usage | drawing 410/430 stainless steel wire from 0.7mm to 0.13mm | ||
Output | 10KG/Hour | ||
Weight | around 1Ton | ||
Works Efficiency | A person can operate 7-8 machines at the same time | ||
Packaging | Wooden case |
